Rotary Type Spin Welding Machine
MODEL: MT 11 VFD, MT 11 SERVO
Rotary Type Spin Welding Machine is engineered for precise and durable joining of thermoplastic components using high-speed rotational friction technology. The machine delivers strong weld quality, high production speed, and consistent industrial performance. Widely used in automotive, packaging, medical, and plastic manufacturing industries, it ensures reliable operation, energy efficiency, and excellent welding accuracy.
Specially developed by MARCK TECHNO, this machine is designed to increase production efficiency while reducing manpower requirements. The welding process works by rotating one plastic component against another under controlled axial pressure. The friction generated at the interface creates heat, allowing the plastic materials to melt and fuse together, resulting in a strong and permanent bond with superior finishing and strength.
- Rotational Unit: This includes a motor and spindle that rotate one of the components. The rotational speed is carefully controlled to ensure optimal heating and fusion.
- Control System: An integrated control panel or computer system manages the machine’s parameters, such as rotation speed, pressure, and welding time. It often includes programmable settings for different welding applications.
Process:
- Preparation: The components to be welded are positioned and clamped into the machine’s fixtures.
- Welding: As the temperature at the interface rises, the plastic melts and begins to fuse.
- The human -computer interface is a 6- inch colour touch screen.
- accurate filling of carbon automatically
- Automatically Jali fitting
Applications:
- Automotive Industry: Joining plastic parts for interior components or assemblies.
- Consumer Goods: Manufacturing items like household appliances or sporting goods.
- Medical Devices: Creating components that require sterile or precise welds.
Advantages:
- Strong Joints: Provides high-strength welds suitable for demanding applications.
- Versatility: Capable of welding various thermoplastic materials.
- Precision: Ensures accurate control over welding parameters, leading to consistent results.
Technical specification:
| MODEL NO | MT 11 VFD | MT 11 SERVO |
| INPUT VOLTAGE | 3-PH, AC | 3-PH, AC |
| MOTOR | VFD+ SERVO MOTOR FOR ROTARY | 3KW SERVO+ SERVO MOTOR FOR ROTARY |
| PRODUCTION SPEED | 4-7 PCS/MINUTE | 4-8 PCS/MINUTE |
| DIMENSIONS (MM) | 1500*700*2200 (L*W*H) | 1500*700*2200 (L*W*H) |
| WEIGHT | 550 KG | 560 KG |
| POWER | 1500W +2000W | 3000W + 2000W |
